Introduction
Elevators serve as indispensable vertical transportation systems in modern buildings, and their operational safety, ride comfort, and reliability directly affect passenger well-being and user experience. At the heart of every elevator control system lies the variable frequency drive (integrated controller), a critical component responsible for motor drive control, motion curve generation, fault protection, and floor dispatching. This article focuses on the NICE1000 series elevator integrated controller, developed by Suzhou MONARCH Control Technology Co., Ltd. Drawing upon the official user manual, this guide systematically covers the product’s characteristics, operation panel usage, parameter system, terminal wiring, commissioning procedures, fault diagnosis methodology, and maintenance practices, providing elevator engineering professionals with a practical and comprehensive reference.
NICE1000 Product Overview and Elevator Applications
Product Positioning and Application Scenarios
The NICE1000 is an elevator-dedicated integrated controller developed by MONARCH Control Technology Co., Ltd. It employs a fully parallel signal transmission architecture, integrating variable frequency drive control with elevator logic control within a single hardware platform. The product is designed around three core principles: high stability, ease of use, and minimal on-site commissioning. It primarily targets two application scenarios: villa elevators and freight elevators.
In elevator applications, the NICE1000 offers the following key advantages:
- Integrated structure: The unified design saves control board mounting space, reduces control cabinet volume, and cuts wiring labor by more than one-fifth compared to conventional freight elevator configurations.
- High-voltage direct input: Three of the 27 digital input channels (X25 through X27) accept high-voltage AC signals, allowing safety circuits, hall door locks, and car door locks to connect directly to the main control board without intermediary contactors, thereby reducing failure points.
- Shared button input/output: The main control board provides 20 button input/output points (L1 through L20). A single signal line handles both button signal acquisition and indicator lamp output. Without expansion, the system supports up to 7 floors in full collective mode or 10 floors in single collective mode.
- Encoder compatibility: The high-speed counter port supports response frequencies up to 80KHz, accommodating encoders of virtually any pulse count. Synchronous motors can be paired with the MCTC-PG-D card for UVW encoders or the MCTC-PG-E card for sine/cosine (SIN/COS) encoders.
- Abundant relay outputs: 21 relay output channels (Y0 through Y22) are organized into 7 common groups, with each terminal’s function being independently configurable. The design supports automatic switching for emergency power backup systems.
Model Naming and Technical Specifications
The NICE1000 model naming convention follows the format “NICE-L-[structure code]-[power rating],” where L denotes elevator-specific application, structure code G corresponds to asynchronous motors, and V corresponds to synchronous motors. For example, NICE-L-G-4015 designates a three-phase 380V elevator integrated controller rated for a 15kW asynchronous motor.
The following table summarizes the key technical specifications:
| Parameter | Specification |
|---|---|
| Maximum frequency | 99Hz |
| Carrier frequency | 0.5kHz to 16kHz (auto-adjustable) |
| Motor control method | Open-loop vector / Closed-loop vector |
| Starting torque | 0.5Hz/180% (open-loop); 0Hz/200% (closed-loop) |
| Speed regulation range | 1:100 (open-loop); 1:1000 (closed-loop) |
| Speed stability accuracy | ±0.5% (open-loop); ±0.05% (closed-loop) |
| Overload capacity | 150% rated current for 60s; 200% rated current for 1s |
| Operating temperature | -10°C to +40°C (derating required for 40°C to 50°C) |
| Altitude | Below 1000m (derating required above) |
Feature Overview
The NICE1000 incorporates nearly 50 standard functions, encompassing inspection operation, direct landing, self-rescue leveling, emergency rescue operation, motor parameter auto-learning, hoistway parameter auto-learning, lock-elevator function, automatic return to base floor, lighting/fan energy saving, front/rear door service floor configuration, overload protection, attendant operation, fire emergency operation, reverse-run protection, anti-slip protection, contactor contact welding protection, encoder fault protection, fault history recording, load weighing signal compensation, pre-torque setting, full/down/up collective operation, door lock short-circuit detection, and ground short-circuit detection. Among these, the power-failure emergency operation scheme automatically releases passengers to the nearest leveling zone after a power outage, serving as a critical safety feature for villa elevators.
Operation Panel and Parameter Configuration
Operation Panel Functions
The NICE1000 is equipped with a 5-digit LED display operation panel capable of showing functional parameters, running speed, DC bus voltage, and other operational data. Indicator LEDs on the panel include RUN (operating status), LOCAL/REMOT (reserved), FWD/REV (elevator up/down direction), and TUNE/TC (tuning status). Unit indicator LEDs cover Hz (frequency), A (current), V (voltage), RPM (rotation speed), and % (percentage).
The operation panel keyboard buttons and their functions are as follows:
| Button | Name | Function |
|---|---|---|
| PRG | Program key | Enter and exit the first-level menu |
| ENTER | Confirm key | Enter next menu level and confirm parameter settings |
| ∧ / ∨ | Increment / Decrement | Increase or decrease data/function codes |
| >> | Shift key | Cycle through LED display parameters; select digit during parameter editing |
| RUN | Run key | Start operation in keyboard control mode |
| STOP/RESET | Stop/Reset key | Stop operation or reset fault alarms |
| MF.K | Multi-function key | Show or hide fault information |
Three-Level Menu System
Parameter configuration on the NICE1000 follows a three-level menu structure: Function parameter group (Level 1) → Function code (Level 2) → Function code setting value (Level 3). For instance, function code F0-05 represents the 5th parameter within the F0 basic parameter group.
When operating in the third-level menu, pressing ENTER saves the parameter and returns to Level 2 while automatically advancing to the next function code. Pressing PRG returns to Level 2 without saving and remains on the current function code. If a function code shows no blinking digit in the third-level menu, it indicates the parameter cannot be modified, possibly because it is a measured value (such as a running record) or it requires the controller to be in a stopped state before modification.
Parameter Group System
The NICE1000 contains 17 parameter groups, each serving a distinct purpose:
| Group | Name | Core Content |
|---|---|---|
| F0 | Basic parameters | Control method, command source, running speed, rated speed, max frequency, carrier frequency |
| F1 | Motor parameters | Encoder type, rated power/voltage/current/frequency/speed, stator/rotor resistance, auto-learning selection |
| F2 | Vector control parameters | Speed loop proportional gain and integral time, current loop gain, torque limit, running direction |
| F3 | Operation control parameters | Acceleration/deceleration, inflection point times, re-leveling speed, forced deceleration switch positions, parking distance margin |
| F4 | Floor parameters | Leveling adjustment, current floor, current position, leveling plate length, floor heights |
| F5 | Terminal input function parameters | X1 through X27 input terminal function definitions, terminal status display |
| F6 | Elevator basic parameters | Highest/lowest floor, parking base, fire base, lock base, service floors, L1 through L26 button definitions |
| F7 | Terminal output function parameters | Y0 through Y23 output terminal function definitions (run contactor, brake, door open/close, 7-segment display, etc.) |
| F8 | Enhanced function parameters | Weighing auto-learning, pre-torque settings, zero-servo parameters, power-failure emergency rescue |
| F9 | Time parameters | Idle return-to-base time, fan off time, max floor-to-floor travel time, accumulated operating hours |
| FA | Keyboard settings | Baud rate, running/stop display parameter selection, encoder angle, software version, heatsink temperature |
| FB | Door function parameters | Door operator quantity, through-door options, door service floors, door open time protection, door hold times |
| FC | Protection function parameters | Ground short-circuit detection, overload protection coefficient, overload warning coefficient, fault history (6 records) |
| FE | Elevator function settings | Collective mode, floor display mapping, external call output encoding, manufacturer function bits (FE-13/FE-14) |
| FP | User parameters | User password (FP-00), parameter update/factory reset (FP-01) |
Key Parameters in Detail
F0 Basic Parameters establish the foundation for elevator operation. F0-00 (control method) determines open-loop (0) or closed-loop (1) vector control. F0-01 (command source) set to 1 enables distance control mode for direct landing. F0-04 (rated elevator speed) has a factory default of 0.500m/s with a range of 0.200 to 1.000m/s. F0-05 (maximum frequency) defaults to 50.00Hz.
F1 Motor Parameters are critical for proper motor operation. F1-00 (encoder type selection) defaults to 1 (UVW incremental) for synchronous motors and 2 (push-pull) for asynchronous motors. F1-11 (auto-learning selection) offers four options: 0 = no operation, 1 = motor tuning with load, 2 = motor tuning without load, 3 = hoistway auto-learning. Synchronous motors must undergo parameter identification before operation.
F3 Operation Control Parameters directly affect ride comfort. F3-02 (acceleration) defaults to 0.300m/s² with a range of 0.200 to 0.800m/s². F3-05 (deceleration) also defaults to 0.300m/s². Inflection point acceleration/deceleration times F3-03/F3-04 default to 2.500s. F3-10 (re-leveling speed) defaults to 0.040m/s, used for door-open re-leveling operation. F3-11 (low-speed running speed) defaults to 0.250m/s.
F5 Terminal Input Functions support 99 function codes for normally open (01-99) and normally closed (101-199) inputs, covering leveling signals (01/02/03), run feedback (04), brake feedback (05/06), inspection signals (09/10/11), fire signal (12), lock signal (14), limit signals (15/16), forced deceleration signals (17/18), overload/full-load signals (19/20), safety circuit (21/36), door lock circuits (37/38), and more. X25 through X27 are high-voltage input terminals rated for AC95V to AC125V, specifically designed for safety circuit and door lock feedback.
FP User Parameters include FP-00 (user password), which when set to a non-zero value requires password entry each time PRG is pressed to access parameter editing. FP-01 (parameter update) provides factory reset (setting = 1) and fault memory clearing (setting = 2) functions. During factory reset, motor parameters, floor parameters, and fault records are preserved.
Wiring and Terminal Definitions
Main Power Circuit Terminals
The NICE1000 main circuit terminals include power input terminals, output drive terminals, DC bus terminals, and braking resistor terminals. For three-phase 380V models, power input connects to terminals R, S, and T. For single-phase or three-phase 220V models, power input connects to L1, L2, and L3. Output drive terminals U, V, and W connect to the three-phase motor. Models rated 30kW and below have built-in braking units; braking resistors connect to the (+) and PB terminals. Models above 37kW require external braking units connected through the (+) and (-) terminals. The PE grounding terminal requires a multi-strand copper grounding wire of 4mm² or larger with grounding resistance not exceeding 4Ω.
Braking resistor selection must strictly follow the manual’s recommended values. For example, NICE-L-G/V-4002 corresponds to a 300W/200Ω braking resistor, NICE-L-G/V-4015 to 4500W/32Ω, and NICE-L-G/V-4030 to 9000W/16Ω. Connecting braking resistors directly across the DC bus (+) and (-) terminals is strictly prohibited and may cause fire.
Main Control Board (MCTC-MCB-G) Terminals
The main control board connects external signals through multiple connector plugs:
- CN10/CN11 (Digital inputs): X1 through X24 are optically isolated inputs with 4.7kΩ input impedance, accepting voltage levels of 13V to 30V with current limited to 5mA. Functions are set via parameters F5-01 through F5-24.
- CN3 (High-voltage inputs and relay outputs): XCM serves as the common point for safety/door lock feedback circuits (AC95V to AC125V). X25 through X27 accept high-voltage safety and door lock feedback signals, configured via F5-25 through F5-27. Y0 through Y3 are relay outputs rated at 5A/250VAC or 5A/30VDC, configured via F7-00 through F7-03, with M0 through M3 as corresponding common terminals.
- CN4/CN5 (Relay outputs): Y6 through Y22 are relay outputs configured via F7-06 through F7-22. YM1 is the common for Y6 through Y9, YM2 for Y10 through Y16, and YM3 for Y17 through Y22.
- CN8/CN9 (Power and floor buttons): 24V accepts external DC24V power input. L1 through L20 are shared button input/indicator output terminals.
- CN2 (Encoder interface): 12V provides DC12V power for the encoder. PGA and PGB accept A-phase and B-phase pulse signals. PGM is the 0V reference. PE connects the encoder cable shield.
Main control board indicators include: ER (fault, red), OK (normal, green), MOD (Modbus communication, blinking green), X1 through X27 (input signal, green), L1 through L20 (button signal, green), and Y0 through Y22 (output signal, green). Jumpers J5 and J6 select communication function (232 serial communication or program download), while J8 controls program download mode (must be set to OFF during normal operation).
Expansion Board (MCTC-KZ-B)
The expansion board mounts onto the main control board via the J11 interface, providing L21 through L26 expanded button input/output points, Y4/Y5 and Y23 expanded relay outputs, Ai/M analog input (0 to 10V, suitable for load weighing signals), and MOD+/MOD- Modbus communication terminals. Jumper J4 enables the Modbus termination resistor, while J12 and J13 enable Modbus communication (set to 485 position; main board J5 and J6 must be disconnected when Modbus is active).
Encoder Wiring Guidelines
Encoder cables must use shielded wiring with the shield connected to PE at the controller end only (single-end grounding). The cable must be routed in a dedicated metal conduit that is reliably grounded, and must not run in parallel with power cables at close range. Push-pull and open-collector incremental encoders connect directly to main board CN2. UVW encoders require the MCTC-PG-D adapter card (DB15 connector), while SIN/COS encoders require the MCTC-PG-E adapter card.
Elevator Operation Control and Commissioning
Commissioning Procedure
NICE1000 elevator commissioning follows a standardized procedure with strict sequential dependencies:
- Peripheral circuit inspection: Verify all wiring is correct and secure. Check motor insulation resistance using a 500V megohmmeter (minimum 5MΩ). Confirm power supply voltage matches the controller’s rated voltage.
- Encoder verification: Confirm encoder type (F1-00) matches the actual encoder. Verify wiring correctness and pulse-per-revolution setting (F1-12, factory default 1024).
- Elevator specification parameter setup: Configure F0 basic parameters (rated speed F0-04, maximum frequency F0-05), F1 motor parameters (power F1-01, voltage F1-02, current F1-03, frequency F1-04, speed F1-05), and F6 floor parameters (highest floor F6-00, lowest floor F6-01).
- Motor parameter tuning: For asynchronous motors, perform static tuning (F1-11 = 2). For synchronous motors, perform initial angle tuning. Ensure no personnel or obstructions are in the motor rotation area before tuning.
- Input/output definition verification: Verify that F5 input terminal functions and F7 output terminal functions match the actual wiring configuration.
- Inspection trial run: Switch to inspection mode. Press up/down buttons to jog the elevator at inspection speed. Verify correct direction of travel and proper encoder feedback.
- Hoistway auto-learning: Move the elevator to the lowest floor leveling position. In inspection mode, press and hold the S1 button on the main control board for approximately 3 seconds, or set F1-11 = 3 to initiate hoistway auto-learning. The system automatically records floor heights and forced deceleration switch positions into the F4 parameter group. If no leveling signal is received within 45 seconds of continuous operation, Err35 (hoistway auto-learning data abnormal) will be triggered.
- Full-speed trial run: After successful hoistway auto-learning, switch to normal mode and perform full-speed trial runs to verify direct landing performance and leveling accuracy.
- Function and comfort commissioning: Adjust F3 running curve parameters (acceleration, deceleration, inflection point times) to optimize ride comfort. Adjust F2 speed loop PI parameters (F2-00 through F2-04) to improve operational stability.
- Leveling accuracy verification: Fine-tune leveling precision using parameter F4-00 (leveling adjustment, range 0 to 60mm, factory default 30mm). If the elevator overshoots the leveling zone, decrease the setting; if it undershoots, increase the setting.
Power-Failure Emergency Operation
The NICE1000 provides three power-failure emergency operation modes:
- Free-fall braking (self-coasting): Applicable to permanent magnet synchronous motors. Upon power failure, the motor U/V/W windings are short-circuited through a sealing contactor, and the brake is released to allow the elevator to coast slowly to the nearest leveling zone. This requires a sealing contactor and FE-13 Bit13 = 1 to enable the self-coasting function. This is the most economical solution.
- UPS-powered operation: Both the main circuit and working power are supplied by a UPS. The elevator runs at the emergency speed set in F8-09 (factory default 0.05m/s) toward the lighter-load direction until a leveling signal is detected. Configuration requires F5-22 = 33 (UPS input active), F7-00 = 32 (power-failure emergency switchover), and F8-10 = 1 (UPS-powered operation).
- 48V battery-powered operation: The main circuit is powered by a 48V battery while the working power is supplied by a UPS. Set F8-10 = 2 for this mode.
To prevent extended rescue operation risks, it is recommended to set FE-13 Bit14 = 1 to enable emergency rescue timeout protection: self-coasting rescue will stop after 100 seconds, and UPS-driven rescue will stop after 50 seconds. For UPS power selection, a 1kVA UPS suits inverters up to 5.5kW, a 2kVA UPS suits 5.5kW to 11kW, and a 3kVA UPS suits 15kW units.
Fault Diagnosis and Safety Protection
Fault Classification System
The NICE1000 incorporates nearly 60 fault diagnosis and protection functions. Faults are classified into five levels based on their impact on system operation:
| Fault Level | System Response |
|---|---|
| Level 1 | Display fault code; elevator operation unaffected |
| Level 2 | Display fault code; disconnect from parallel system; normal operation permitted |
| Level 3 | Display fault code; in distance control mode, stop at nearest landing then prohibit operation; in other modes, immediate stop |
| Level 4 | Display fault code; immediately block output and close brake; low-speed operation permitted after stop (inspection/re-leveling) |
| Level 5 | Display fault code; immediately block output and close brake; all operation prohibited |
Common Fault Codes and Countermeasures
The system stores the 6 most recent fault records (FC-04 through FC-09). Each fault record is a 4-digit number where the upper two digits represent the floor where the fault occurred and the lower two digits represent the fault code. For example, FC-09 displaying 0135 indicates the most recent fault was Err35, occurring at Floor 1. Parameters FC-10 through FC-12 additionally record the speed, current, and DC bus voltage at the time of the most recent fault.
The following table lists common fault codes with their descriptions and typical causes:
| Code | Description | Common Causes | Level |
|---|---|---|---|
| Err01 | Inverter unit protection | Output ground/short circuit, excessive motor cable length, overheating | 5 |
| Err02 | Acceleration overcurrent | Output short circuit, motor not tuned, excessive load | 5 |
| Err05 | Acceleration overvoltage | Input voltage too high, severe reverse pulling, braking resistor issue | 5 |
| Err09 | Undervoltage fault | Momentary power loss, input voltage too low | 5 |
| Err11 | Motor overload | FC-02 improperly set, brake circuit abnormal, excessive load | 3 |
| Err14 | Module overheating | Ambient temperature too high, fan failure, blocked airway | 5 |
| Err16 | Encoder fault | Startup position fault, torque deviation, speed deviation exceeding 25% of rated | 5 |
| Err22 | Leveling signal abnormal | Leveling/door zone signal stuck or disconnected | 1 |
| Err30 | Elevator position abnormal | Encoder position deviation, leveling signal issue, rope slip | 4 |
| Err35 | Hoistway learning data abnormal | Not starting from lowest floor, no leveling signal within 45s, floor spacing too small | 4 |
| Err36 | Run contactor feedback abnormal | Contactor not engaged when brake opens, feedback signal lost or welded | 5 |
| Err37 | Brake contactor feedback abnormal | Brake output and feedback signal mismatch | 5 |
| Err41 | Safety circuit open | Safety circuit signal disconnected, external power issue | 5 |
| Err42 | Door lock open during operation | Door lock circuit feedback disconnected during running | 5 |
| Err48/49 | Door open/close fault | Consecutive door open/close failures exceeding FB-09 setting | 5 |
Safety Protection Functions
Beyond fault alarms, the NICE1000 features multiple active safety protection functions. Power-on short-circuit detection (FC-00 = 1) tests the motor output for ground faults at power-up, blocking output and triggering Err23 if a fault is detected. Anti-slip protection uses F9-02 (maximum floor-to-floor travel time, up to 45 seconds) to detect rope slip when no leveling signal is received. Contactor contact welding protection monitors run and brake contactor feedback. Door lock short-circuit detection (FE-13 Bit15 = 1) checks for door lock anomalies each time the door opens. Forced deceleration switch welding detection (FE-14 Bit5 = 1) continuously monitors the forced deceleration switches during operation. The overload protection coefficient is set via FC-02 (when output current reaches FC-02 × motor rated current and persists for the inverse-time curve duration, Err11 is triggered), and the overload warning coefficient FC-03 defaults to 80%.
Maintenance and Upkeep
Daily Maintenance
Daily inspection items include: checking for abnormal motor sounds during operation, detecting excessive vibration, monitoring changes in the controller’s installation environment, verifying cooling fan operation, and checking for controller overheating. Daily cleaning should maintain the controller in a clean state, removing surface dust (especially metallic dust) and clearing oil contamination from cooling fans.
Periodic Maintenance
Periodic maintenance items include: inspecting and cleaning air ducts, checking screw tightness, examining the controller for corrosion, inspecting terminal connections for scratches or damage, and performing main circuit insulation testing. Insulation testing must use a DC 500V megohmmeter with the main circuit wiring disconnected from the vector control unit. Do not test control circuit insulation with a megohmmeter. High-voltage testing is unnecessary as it is performed at the factory.
Consumable Parts Replacement
The primary consumable components of the NICE1000 are the cooling fan and filter electrolytic capacitors. Their service life depends on operating environment and maintenance quality:
| Component | Typical Life | Failure Causes | Assessment Criteria |
|---|---|---|---|
| Cooling fan | 2-3 years | Bearing wear, blade aging | Blade cracks, abnormal vibration noise at startup |
| Filter capacitor | 4-5 years | Poor power quality, high ambient temperature, frequent load transients, electrolyte aging | Fluid leakage, safety valve protrusion, decreased capacitance |
Maintenance Safety Precautions
When performing maintenance on the controller, power must be disconnected. After disconnection, the filter capacitors retain hazardous voltage, and maintenance must not begin immediately. Wait 2 to 3 minutes, then verify with a multimeter that the DC bus voltage does not exceed AC36V before proceeding. When replacing the controller, all parameters must be reconfigured, and all removable plugs must be inserted or removed only with power off. For long-term storage, the controller must be powered on at least once every 2 years for a minimum of 5 hours, with input voltage gradually raised to the rated value using a voltage regulator.
Motor Insulation Testing
Motor insulation testing should be performed during initial use, after prolonged storage, and during periodic inspections. The motor wiring must be disconnected from the controller before testing. Use a 500V megohmmeter and ensure insulation resistance is no less than 5MΩ. Additionally, if the controller’s rated power exceeds the motor’s rated power, motor protection parameters (FC-02) must be adjusted accordingly, or a thermal relay must be installed upstream of the motor.
Conclusion
The NICE1000 series elevator integrated controller, with its unified structural design, comprehensive feature set, robust fault protection system, and flexible parameter configuration capabilities, has established a solid application foundation in the villa elevator and freight elevator sectors. This article has systematically covered the complete knowledge chain from product overview, operation panel usage, parameter system, terminal wiring, and commissioning procedures to fault diagnosis and maintenance practices, based on the official user manual.
In practical engineering applications, technical personnel should pay particular attention to the following key points. First, synchronous motors must undergo parameter auto-learning and initial angle tuning before operation; failure to do so may result in safety hazards. Second, hoistway auto-learning must be initiated from the lowest floor leveling position in inspection mode, with verified proper operation of leveling sensors and forced deceleration switches. Third, when modifying parameters, attention must be paid to the operation attribute markers (☆ = modifiable in both stop and run states; ★ = modifiable only in stop state; ● = read-only measured value) to avoid attempting to modify restricted parameters during operation. Fourth, fault troubleshooting should combine the fault level, fault code, and the speed/current/bus voltage data recorded in FC-10 through FC-12 for comprehensive analysis, rather than relying solely on the fault code itself. Fifth, timely replacement of cooling fans and electrolytic capacitors during periodic maintenance is the key preventive measure against sudden failures.
Mastering the NICE1000’s parameter system and commissioning methodology not only improves elevator installation and commissioning efficiency but also enables rapid problem identification and minimized downtime when faults occur, ultimately ensuring safe and reliable elevator operation.
