Inovance MD320/MD320N Series General-Purpose Inverter User Guide: Operation Panel, Terminal Control and Fault Troubleshooting

Introduction to the MD320/MD320N Modular Inverter Platform

The Inovance MD320/MD320N series represents a modular approach to general-purpose variable frequency drive design. Rather than offering multiple separate product lines for different performance levels, the MD series employs a three-layer modular architecture: a high-performance motor control module at the base, a general-purpose function module in the middle, and industry-specific application modules at the top. The MD320 serves as the mid-layer function module, providing a comprehensive set of control capabilities including sensorless vector control (SVC), closed-loop vector control (VC), and V/F control within a single hardware platform.

The MD320N is a structural and cosmetic upgrade of the MD320, offering the same functionality but with an improved enclosure design. Key differences between the MD320N and MD320 include: a three-part enclosure (front cover, middle shell, bottom shell) in light gray versus the MD320’s two-part design (top and bottom plates) in Inovance blue; an internal heatsink enclosed by the bottom shell rather than exposed; a snap-in fan design eliminating mounting screws; a detachable operation panel; and fence-style cable openings instead of rubber-sealed knockouts. The MD320N also has different mounting dimensions, requiring its own dimension tables during installation planning.

MD320N Model Features and Naming Rules

Model Naming Convention

The MD320/MD320N model number follows a structured naming format:

MD320[N] – [Voltage] [Power] [Load Type] [Brake Unit]

• MD320N: The “N” suffix denotes the upgraded enclosure design. Models without “N” use the original MD320 enclosure.
• Voltage class: S = Single-phase 220V; T = Three-phase 380V; 7T = Three-phase 690V
• Power rating: Numerical value in kW (e.g., 0.4, 0.7, 7.5, 55, 450)
• Load type: G = General-purpose (constant torque, heavy duty); P = Pump/fan (variable torque, light duty)
• Brake unit: B = Built-in brake unit; blank = no built-in brake unit
• Narrow body: H suffix indicates a narrow-body enclosure for space-constrained installations (e.g., MD320T110GH)

For example, model MD320NT7.5GB represents an MD320N-series, three-phase 380V, 7.5kW, general-purpose inverter with built-in brake unit. Model MD320-7T132GH represents a three-phase 690V, 132kW, general-purpose, narrow-body inverter.

MD320N Series Technical Data

The MD320N series covers power ratings from 0.4kW to 450kW across three voltage classes. Representative models for the three-phase 380V class include:

Model	Power (kW)	Input Current (A)	Output Current (A)	Frame Size
MD320NT0.7GB	0.75	3.4	2.5	Small
MD320NT2.2GB	2.2	8.1	5.0	Small
MD320NT7.5GB	7.5	21	17	Medium
MD320NT22G	22	53	45	Large
MD320NT55G	55	133	110	Large
MD320NT132G	132	294	260	Extra large

Comparison with MD300 Function Module

The MD320 function module offers significantly more capability than the MD300 module within the same MD series platform:

Feature	MD320	MD300
Digital inputs	5 DI (bidirectional, 1 high-speed)	4 DI (unidirectional, 1 high-speed)
Control modes	SVC, VC, V/F	SVC, V/F (no closed-loop VC)
Multi-step speed	16 speeds	4 speeds
Simple PLC	16-stage timed operation	None
Wobble frequency	Yes	No
PID control	Yes	No
Multi-point V/F	Yes	No
Communication	Via expansion cards	Via dedicated card only

Operation Panel and Parameter Settings

LED Operation Panel

The MD320/MD320N is equipped with a standard LED operation panel that provides parameter display, modification, and basic operation control. The panel features a four-digit LED display, RUN/STOP keys, navigation keys (▲/▼ for increment/decrement), a SHIFT key for digit position selection, a PRG/ESC key for menu entry/exit, and an ENTER/SET key for confirmation. The MD320N’s detachable panel design allows the panel to be removed and reinstalled without tools, simplifying maintenance and panel relocation.

The panel operates in three primary modes:

• Normal display mode: Shows the current operating frequency by default. Other parameters (output current, DC bus voltage, motor speed, etc.) can be selected via the navigation keys. The display alternates between the setpoint frequency and the actual output frequency during operation.
• Parameter editing mode: Accessed via the PRG key. Parameters are organized into functional groups (F0 through FP), and individual parameters within each group can be viewed and modified. Modified parameters are stored in non-volatile memory after pressing ENTER.
• Quick menu mode: Provides rapid access to the most frequently used parameters (motor nameplate data, frequency source, command source, accel/decel time) without navigating through the full parameter tree. This streamlines initial commissioning.

Parameter Group Structure

The MD320/MD320N parameters are organized into the following functional groups:

Group	Name	Key Parameters
F0	Basic function	F0-00 (control mode), F0-01 (command source), F0-02 (frequency source), F0-10 (max frequency), F0-15 (carrier frequency), F0-17/F0-18 (accel/decel time)
F1	Motor parameters	F1-00 to F1-05 (nameplate data), F1-06 to F1-10 (tuned electrical parameters), F1-11 (tuning mode)
F2	Vector control	F2-00 to F2-05 (speed loop PI gains and switching frequencies), F2-06 (slip compensation), F2-07 (speed filter), F2-08 (torque control enable)
F3	V/F control	V/F curve, torque boost, voltage compensation, stall prevention
F4	Input terminals	F4-00 to F4-09 (DI1-DI10 function), F4-10 (DI filter time), F4-11 (terminal command mode), F4-13 to F4-27 (AI1-AI3 scaling), F4-28 to F4-32 (pulse input)
F5	Output terminals	DO1, DO2, relay, AO1, AO2 function assignment and scaling
F6	Start/stop control	Start mode, stop mode, DC injection braking, S-curve
F7	Keyboard and display	Display selection, load speed coefficient, temperature display, running time, software version
F8	Auxiliary functions	Jog, multi-step accel/decel, jump frequency, FDT, droop control, overmodulation
F9	Fault and protection	Motor overload, overvoltage stall, undervoltage, phase loss, ground short
FA	PID control	PID setpoint, feedback, gains, limits
FB	Wobble frequency and counting	Traverse winding, fixed length, counter
FC	Multi-step speed and PLC	16-speed settings, 16-stage PLC with time, direction, and accel/decel
FD	Communication	Modbus-RTU parameters
FP	User password	Password setting, parameter initialization

Motor Parameter Auto-Tuning

The MD320 supports two motor tuning methods through parameter F1-11:

• F1-11 = 1: Static tuning (静止调谐) — Identifies stator resistance, rotor resistance, and leakage inductance without rotating the motor. Suitable when the motor cannot be disconnected from the load. The drive applies test signals to the motor while stationary and calculates the electrical parameters. Tuning accuracy is moderate.
• F1-11 = 2: Complete tuning (完整调谐) — Performs static tuning first, then drives the motor through acceleration to 80% of rated frequency, holds, and decelerates to zero. This identifies all motor parameters including mutual inductance and no-load current. The motor must be disconnected from the load (no-load condition). Tuning accuracy is best.

During tuning, the display shows “TUNE” (flashing after ENTER, steady after RUN). The process can be aborted with the STOP key. Upon completion, F1-11 automatically resets to 0, and the identified parameters are written to F1-06 through F1-10. If tuning cannot be performed, parameters from a previously tuned motor of the same model can be manually entered.

Speed Loop PI Tuning (F2 Group)

The MD320 provides dual-zone speed loop PI parameters for optimal response across the full speed range:

• Low-speed zone (below F2-02, default 5.00 Hz): F2-00 (proportional gain, default 30) and F2-01 (integral time, default 0.50s). Higher gain and shorter integral time provide faster response at low speeds where motor back-EMF is low.
• High-speed zone (above F2-05, default 10.00 Hz): F2-03 (proportional gain, default 15) and F2-04 (integral time, default 1.00s). Lower gain and longer integral time prevent oscillation at high speeds.
• Transition zone (between F2-02 and F2-05): PI parameters are linearly interpolated between the two zones for smooth transition.

The recommended tuning procedure is: increase proportional gain until the system just begins to oscillate, then reduce it slightly; then reduce integral time until oscillation appears, then increase it slightly. This achieves fast response with minimal overshoot. If PI parameters are set too aggressively, speed overshoot during deceleration can trigger overvoltage faults.

Main Circuit and Control Terminal Wiring

Main Circuit Terminals

The MD320 main circuit terminals follow the standard Inovance convention:

Terminal	Name	Description
R, S, T	Three-phase power input	Connect to three-phase AC supply (380V for T-type, 220V for S-type, 690V for 7T-type)
U, V, W	Motor output	Connect to three-phase motor
P(+), N(-)	DC bus	For external brake unit connection or DC bus sharing
P(+), BR	Brake resistor	For models with built-in brake unit (B suffix), connect brake resistor here
PE	Protective earth	Must be connected to system ground

The MD320 comes with a standard built-in DC reactor on all models, which improves power factor and reduces input harmonic current without requiring an external AC input reactor in most applications.

Control Terminal Wiring

The MD320 standard control terminal block provides:

Category	Terminals	Specifications
Power supply	+10V-GND	+10V reference, max 10mA, for 1kΩ-10kΩ potentiometer
Power supply	+24V-COM	+24V for DI/DO, max 200mA; OP terminal provides DI common
Analog inputs	AI1, AI2	0-10V or 0/4-20mA, selectable via jumper; input impedance 100kΩ (voltage) or 500Ω (current)
Digital inputs	DI1-DI5	24V level (bidirectional), DI5 supports high-speed pulse input up to 50kHz
Digital outputs	DO1, DO2	Optocoupler isolated, open-collector, 0-24V, max 50mA; DO1 supports high-speed pulse output
Relay output	TA, TB, TC	Dry contact, AC 250V/3A (cosφ=0.4), DC 30V/1A; TA-TC normally open, TB-TC normally closed
Analog output	AO1	0-10V or 0/4-20mA, selectable via jumper
Communication	RS+, RS-	RS485 for Modbus-RTU (via expansion card on MD320; built-in on some models)

Terminal Command Modes (F4-11)

The MD320 supports four terminal command modes for flexibility in control wiring:

• F4-11 = 0: Two-wire mode 1 — DI1 = forward run/stop, DI2 = reverse run/stop. The motor runs when DI1 or DI2 is active and stops when inactive. Both active simultaneously is invalid.
• F4-11 = 1: Two-wire mode 2 — DI1 = run/stop, DI2 = forward/reverse. DI1 controls start/stop while DI2 selects direction.
• F4-11 = 2: Three-wire mode 1 — Uses a momentary start button (DI1), momentary reverse button (DI2), and maintained stop button (DI3). Similar to a conventional motor starter circuit with forward/reverse/stop pushbuttons.
• F4-11 = 3: Three-wire mode 2 — Uses a momentary start button (DI1), maintained forward/reverse selector (DI2), and maintained stop button (DI3).

Expansion Cards

The MD320 supports several expansion cards for extended functionality:

• MD32PG/MD32PGD: Standard PG (encoder) card for closed-loop vector control. MD32PG provides encoder signal input (open-collector or push-pull, +15V power, 80kHz max). MD32PGD adds frequency division output (adjustable 4-62 via 5-bit DIP switch, open-collector output, 100mA max). The card has 9 terminals: +15PG/COM (encoder power), PGA/PGB (signal input), OUT-A/OUT-B/COM (division output), PE (shield).
• MD32PG3: Long-line driver PG card for differential encoder signals, supporting higher noise immunity over long cable runs.
• MD32IO: IO expansion card adding AI3 (analog input), AO2 (analog output), DI6-DI10 (5 additional digital inputs), DO2 (additional digital output), and a second relay output. This card significantly expands the control capability for complex applications.
• MD32MBS: Communication card providing RS485 Modbus-RTU communication for models without built-in RS485.
• MDCP: Parameter copy card for uploading parameters from one drive and downloading to another, enabling rapid configuration of multiple identical drives without a laptop.

V/F Control and Vector Control Modes

Control Mode Selection (F0-00)

The MD320 supports three motor control modes selectable through parameter F0-00:

• F0-00 = 0: Sensorless vector control (SVC) — Provides high-performance torque and speed control without an encoder. The drive estimates motor flux and rotor speed using a motor model based on stator current and voltage measurements. SVC achieves starting torque of 150% at 0.5 Hz and speed accuracy of ±0.5%. It is suitable for most high-performance single-motor applications including machine tools, wire drawing machines, and injection molding machines.
• F0-00 = 1: Closed-loop vector control (VC) — Uses encoder feedback for precise speed and torque control. Requires a PG card (MD32PG or MD32PGD) and an encoder mounted on the motor. VC achieves speed accuracy of ±0.02%, full rated torque at zero speed, and position control capability. It is recommended for high-precision applications such as paper machines, cranes, and positioning systems.
• F0-00 = 2: V/F control — Scalar voltage/frequency control suitable for multi-motor applications (one drive driving multiple motors) or applications with low control requirements. V/F control does not require motor parameter auto-tuning. The MD320 supports multi-point V/F curves (up to 4 programmable points), allowing custom V/F profiles for specialized loads.

V/F Control Parameters (F3 Group)

When using V/F control, the F3 group parameters configure the voltage-frequency relationship:

• F3-00: V/F curve mode — 0: linear, 1: multi-point, 2: squared (for pump/fan loads)
• F3-01 through F3-04: Multi-point V/F curve parameters (frequency and voltage at each point)
• F3-05: Torque boost (0.0-10.0%) — increases output voltage at low frequencies to compensate for stator resistance voltage drop, improving starting torque
• F3-06: Torque boost cutoff frequency (0-50 Hz) — above this frequency, torque boost is disabled
• F3-07: V/F slip compensation gain — compensates for motor slip under load to improve speed regulation in V/F mode

Stall Prevention Parameters

The MD320 includes overvoltage and overcurrent stall prevention to avoid nuisance tripping during transient conditions:

• F9-03: Overvoltage stall gain (0-100) — higher values provide stronger suppression. For small-inertia loads, use lower values to avoid sluggish response. For large-inertia loads, use higher values to prevent overvoltage trips during deceleration.
• F9-04: Overvoltage stall protection voltage (120-150%, default 130% of rated DC bus voltage) — the DC bus voltage level at which stall prevention activates. When the bus voltage exceeds this threshold during deceleration, the drive temporarily reduces deceleration rate to prevent overvoltage.
• F9-05: Overcurrent stall gain and action current — controls the overcurrent stall prevention during acceleration. When output current exceeds the action threshold, the drive temporarily reduces acceleration rate.

Typical Applications

Textile Machinery

The MD320’s wobble frequency function (FB group) makes it well-suited for textile bobbin winding applications. The wobble frequency superimposes a triangular wave on the base frequency, causing the motor speed to oscillate around the setpoint. This ensures uniform yarn distribution across the bobbin width. Parameters FB-00 through FB-07 configure the wobble amplitude, frequency, and base frequency, allowing precise adaptation to different yarn types and bobbin sizes.

Pump and Fan Control

For pump and fan applications, the MD320 offers:

• Built-in PID control (FA group) with feedback from pressure or flow sensors, enabling constant-pressure water supply systems
• Squared V/F curve (F3-00 = 2) optimized for centrifugal loads, reducing energy consumption at partial loads
• Multi-pump alternation logic via the simple PLC function, sequencing between lead and lag pumps based on demand
• Sleep/wake function for automatic shutdown during low-demand periods, reducing energy waste and equipment wear
• P-type load rating providing cost-effective sizing for variable-torque loads

Wire Drawing and Extrusion

For wire drawing machines, the MD320 provides:

• 16-step multi-speed operation (FC group) for different wire diameters and drawing speeds
• Droop control (F8-15) for load sharing when multiple motors drive a common capstan
• Torque control (F2-08) for maintaining constant tension on the wire
• Closed-loop vector control for precise speed synchronization between drawing stages
• Simple PLC (FC group) for automated sequence operation with up to 16 stages, each with configurable run time, direction, frequency, and accel/decel time

Modbus-RTU Communication

The MD320 supports Modbus-RTU communication through the FD group parameters and the built-in RS485 port or the MD32MBS communication expansion card:

Parameter	Name	Default	Range
FD-00	Communication protocol	Modbus-RTU	Modbus-RTU
FD-01	Baud rate	9600	300-115200 bps
FD-02	Data format	8-N-2	8-N-1, 8-N-2, 8-E-1, 8-O-1
FD-03	Slave address	1	1-247
FD-04	Communication timeout	0.0s (disabled)	0.0s or 0.1-60.0s

The Modbus protocol supports function codes 0x03 (read holding registers) and 0x06 (write single register). Parameter addresses follow the Inovance convention: the address is constructed from the group number (high byte) and parameter number (low byte). For example, F0-10 (maximum frequency) has address 0x000A. Writing to address 0x0F0A stores the value in EEPROM; writing to 0x000A stores in RAM only (useful for frequent writes to extend EEPROM life). The communication also supports special addresses for control commands (0x2000), drive status (0x3000), and fault codes (0x8000).

Fault Codes and Troubleshooting

The MD320 implements 24 fault types with comprehensive diagnostic information. When a fault occurs, the drive stops output, the fault relay activates, and the fault code is displayed on the operation panel. The three most recent faults are stored in the drive’s non-volatile memory for diagnostic purposes.

Code	Fault Name	Cause	Solution
Err01	Inverter unit protection (逆变单元保护)	IGBT overcurrent or overvoltage detected by hardware protection circuit; output ground short; module damage	Check motor and output cable for short/ground fault; check motor insulation with megger; if no external fault found, contact service — module may be damaged
Err02	Acceleration overcurrent	Output short/ground; motor not tuned; accel too short; torque boost too high; starting rotating motor	Check motor/cable insulation; perform tuning (F1-11); increase accel time (F0-17); reduce torque boost (F3-05); enable speed tracking start
Err03	Deceleration overcurrent	Output short; decel too short; no brake resistor; large inertia	Check output wiring; increase decel time (F0-18); install brake resistor; tune stall prevention (F9-03/F9-04)
Err04	Constant speed overcurrent	Output ground fault; load surge; undersized drive	Check motor insulation; verify drive sizing; investigate load for jams or blockages
Err05	Acceleration overvoltage	Input voltage high; external force driving motor; no brake resistor	Check input voltage; install brake resistor; enable overvoltage stall (F9-03); adjust F9-04
Err06	Deceleration overvoltage	Decel too short; high inertia; no brake unit	Increase decel time; install brake unit/resistor; enable and tune overvoltage stall prevention
Err07	Constant speed overvoltage	Input voltage high; external force; large inertia	Reduce input voltage; install brake resistor; check for overhauling loads
Err08	Control power fault	Control power supply voltage abnormal; internal power supply failure	Check input voltage stability; if persistent, contact service — control board power supply may be faulty
Err09	Undervoltage	Input voltage low; phase loss; power supply insufficient; contactor fault	Check power supply voltage and phases; verify contactor operation; check for loose input wiring
Err10	Inverter overload	Load exceeds rated current; poor ventilation; high ambient	Reduce load; improve ventilation; verify drive sizing; reduce carrier frequency (F0-15) to lower internal heat
Err11	Motor overload	Motor overloaded; F9-01 incorrect; motor parameters wrong	Reduce load; verify F9-01 matches motor rated current; check F1-00 to F1-05; perform motor tuning
Err12	Input phase loss	Input phase lost; loose wiring; faulty contactor; surge protector failure	Check three-phase input voltage; check input wiring and contactor; inspect surge protector (防雷板)
Err13	Output phase loss	Output cable loose; motor winding open; output contactor fault	Check output wiring continuity; check motor winding resistance; inspect output contactor
Err14	Module overheat	Radiator temperature exceeded; fan failed; airway blocked; high ambient; carrier frequency too high	Clean airway and heatsink; replace fan; reduce ambient temperature; lower carrier frequency (F0-15); reduce load
Err15	External fault	External fault DI signal triggered; external protection device activated	Check external fault source and circuit; clear external fault condition
Err16	Communication fault	RS485 cable disconnected; baud rate mismatch; slave address conflict; communication timeout	Check RS485 wiring; verify FD-01 baud rate and FD-03 address match host; check FD-04 timeout; verify host is running
Err17	Contactor fault	Soft-start contactor not engaging; coil voltage low; contactor mechanical wear; 24V supply fault	Check contactor cable connections; measure contactor coil voltage; inspect contactor contacts; check 24V power supply
Err18	Current detection fault	Current sensor failure; driver board hardware fault; 4-pin ribbon cable loose	Check 4-pin ribbon cable between driver board and control board; if persistent, contact service
Err19	Motor tuning fault	Tuning failed; motor parameters incorrect; encoder signal issue; motor not disconnected from load	Verify F1-00 to F1-05 nameplate data; disconnect motor from load for complete tuning; check encoder wiring and PG card
Err20	Encoder fault (码盘故障)	Encoder wiring broken; PG card not installed; encoder type mismatch; encoder power failure	Check encoder wiring continuity; verify PG card installation; check encoder power (+15PG); verify encoder parameters
Err21	Data overflow (数据溢出)	Internal parameter data corruption; EEPROM read/write error	Power cycle the drive; if persistent, perform parameter initialization (FP-01 = 1) and reconfigure; contact service
Err22	Inverter hardware fault	Hardware overcurrent or overvoltage detected; internal component failure; most commonly hardware overvoltage	Check for output short circuits; check input voltage; if no external cause found, contact service immediately — do not repeatedly reset
Err23	Ground short circuit	Motor winding grounded to frame; output cable insulation damaged	Megger test motor and output cable (500V DC, disconnect from drive first); repair or replace damaged components; verify F8-22 power-on ground short detection

Common Troubleshooting Scenarios

Beyond the fault codes, the MD320 manual provides troubleshooting guidance for common operational issues:

Symptom	Possible Cause	Solution
No display on power-up	Input power not connected; 8-pin ribbon cable between driver board and control board loose; internal component failure	Check input power; reseat 8-pin ribbon cable; contact service if persistent
Display shows “HC” on power-up	4-pin ribbon cable between driver board and control board loose; internal component failure	Reseat 4-pin ribbon cable; contact service if persistent
Err23 on power-up	Motor or output cable ground short; drive damage	Megger test motor and cable; contact service if insulation is normal
Normal power-up, “HC” on run then stop	Cooling fan failed or seized	Replace cooling fan
Frequent Err14 (overheat)	Carrier frequency too high; fan failed; airway blocked; internal thermal sensor fault	Reduce carrier frequency (F0-15); replace fan; clean airway; contact service if all else fails
Motor does not rotate after run command	Motor damaged or mechanically jammed; F1 group parameters incorrect	Check motor and mechanical load; verify and reconfigure F1 group motor parameters; perform tuning
DI terminals not functioning	F4 group parameters incorrect; OP to +24V shorting bar loose; control board fault	Check and reconfigure F4 parameters; verify OP-+24V jumper; contact service if persistent
Speed cannot increase in VC mode	Encoder damaged or miswired; internal component failure	Replace encoder; verify encoder wiring; contact service
Frequent overcurrent/overvoltage	Motor parameters incorrect; accel/decel time unsuitable; load fluctuation	Reconfigure F1 parameters or perform tuning; adjust accel/decel times; investigate load conditions

EMC Considerations

The MD320/MD320N complies with IEC/EN 61800-3:2004 EMC standards for adjustable speed drive systems. To achieve EMC compliance, the following installation practices are recommended:

• Install the drive on a metal panel and ground the PE terminal with adequate cross-section conductor
• Route power cables and control cables in separate conduits with at least 100mm separation
• Use shielded cables for motor connections, with the shield grounded at both ends using 360° clamps
• Install an EMC input filter for residential or commercial environments (Category C2)
• Install an output reactor for motor cable lengths exceeding 100m
• Avoid installing power factor correction capacitors or surge suppressors on the drive output side
• Ensure all contactors and relays near the drive have surge suppressors installed across their coils

Leakage current is a common concern with VFD installations. The MD320 generates leakage current due to PWM output voltage dV/dt and parasitic capacitance in motor cables. Mitigation measures include reducing carrier frequency (F0-15), shortening motor cables, using shielded cables with lower capacitance, installing output reactors, and using type B RCDs with time delay for ground fault protection.

Conclusion

The Inovance MD320/MD320N series general-purpose inverter provides a versatile and cost-effective drive solution through its modular three-layer architecture. The support for all three major control modes — sensorless vector control, closed-loop vector control, and V/F control — within a single hardware platform eliminates the need for multiple drive models, reducing inventory complexity and total cost of ownership.

The comprehensive parameter group structure (F0 through FP) covers every aspect of drive operation, from basic frequency control to advanced application functions including PID, multi-step speed, simple PLC, wobble frequency, and torque control. The dual-zone speed loop PI parameters in the F2 group enable optimal dynamic response across the full speed range, while the stall prevention functions in F9 protect against nuisance tripping during transient conditions.

The expansion card ecosystem — including PG cards for closed-loop control, IO expansion cards for complex control schemes, communication cards for network integration, and parameter copy cards for rapid deployment — extends the MD320’s capability far beyond its standard configuration. The Modbus-RTU communication protocol provides reliable integration with PLCs and SCADA systems, with comprehensive address mapping for remote monitoring and control.

The 24 fault codes with detailed troubleshooting flowcharts and diagnostic guidance enable maintenance personnel to quickly identify and resolve issues, minimizing downtime. Combined with the EMC-compliant installation guidelines and the structural improvements of the MD320N enclosure design, the MD320/MD320N series delivers the performance, flexibility, and reliability required for diverse industrial drive applications from textile machinery to pump stations to wire drawing lines.
